NicNac

Step by step

1. 1

   Measure and mark

   Place the French cleat wall bracket against the wall at the desired height. Use a spirit level to ensure it is straight. Mark the mounting holes on the wall through the holes in the bracket.
2. 2

   Drill holes

   • For masonry or concrete walls: Drill holes at the marked positions using a 6 mm drill bit. Drill to a depth of 45 mm. Ensure you drill straight (perpendicular to the wall).
   • For plasterboard walls: Drill through the board with the same bit and use the wall plugs from the box.
   • For wooden walls: Do not use the 6 mm bit. Instead, pre-drill 2 mm pilot holes for the mounting screws. Wall plugs are not needed for wood.
3. 3

   Insert wall plugs

   Insert the provided 6 mm wall plugs into the drilled holes (not in a wooden wall).
4. 4

   Mount the bracket

   Align the French cleat wall bracket with the holes (or wall plugs). Using the TX15 bit, drive the mounting screws into the wall to secure the bracket.

   Important: Do not overtighten the screws, as this may damage the bracket or the wall.
5. 5

   Mount the shelving unit

   Lift the NicNac shelving unit. Lower it onto the French cleat wall bracket until it sits securely and evenly against the wall.
