Wasteless

Step by step

1. 1

   Measure and mark

   Hold the Wasteless wall shelf against the wall at the desired height. Use a spirit level to ensure it is straight. Mark the mounting points on the wall based on the holes in the central dowel.
2. 2

   Drill holes

   • For masonry or concrete walls: Drill holes at the marked positions using a 10 mm drill bit.
   • For plasterboard walls: Drill through the board with the same bit and use the wall plugs from the box.
   • For wooden walls: Do not use the 10 mm bit. Instead, pre-drill 6 mm pilot holes for the mounting screws. Wall plugs are not needed for wood.

   Important: Always drill straight (perpendicular to the wall).
3. 3

   Insert wall plugs

   Insert the provided 10 mm wall plugs into the drilled holes (not in a wooden wall).
4. 4

   Install mounting screws

   Place a brass washer onto each T25 mounting screw. Using the T25 bit, drive the mounting screws into the wall (or wall plugs). Tighten until the washers sit flush against the wall.
5. 5

   Attach brass tubes

   Slide a brass tube over each exposed mounting screw head, covering the washer and screw.
6. 6

   Mount the shelf

   Place the Wasteless wall shelf onto the wall-mounted screws/tubes. Secure the shelf by tightening the pre-inserted set screws on the back of the central dowel using the 3 mm hex key.

   Important: Do not overtighten, as this may affect the stability of the shelf.
