Adapt

Step by step

1. 1

   Measure and mark

   Hold the Adapt coat rack against the wall at the desired height. Use a spirit level to ensure it is straight. Mark the position of the mounting points on the wall based on the pins on the back of the rack.

   Note: The distance between pins varies by model. Always measure your specific unit.
2. 2

   Drill holes

   • For masonry or concrete walls: Drill holes at the marked positions using a 10 mm drill bit. Drill to a depth of 70 mm. Ensure you drill straight (perpendicular to the wall).
   • For plasterboard walls: Drill through the board with the same bit and use the wall plugs from the box.
   • For wooden walls: Do not use the 10 mm bit. Instead, pre-drill 6 mm pilot holes for the mounting screws. Wall plugs are not needed for wood.
3. 3

   Insert wall plugs

   Insert the provided 10 mm wall plugs into the drilled holes (not in a wooden wall).
4. 4

   Install mounting screws

   Place a brass washer onto the thread of each T25 mounting screw. Using the T25 bit, drive the mounting screws into the wall (or wall plugs) until the washers sit flush against the wall surface.
5. 5

   Attach brass covers

   Slide the brass covers over the exposed heads of the mounting screws.
6. 6

   Mount the coat rack

   Align the back of the Adapt coat rack with the mounting screws. Push the rack onto the mounts. Secure the rack by tightening the pre-inserted set screws using the 3 mm hex key.
